5MP EVO SERIES OUTDOOR FIXED TURRET NETWORK CAMERA
• 5MP @ 30fps
• Max. resolution: 2592x1944
• Supports H.265 / H.264 Video Compression
• 2.8mm Fixed Focal Lens
• Smart IR Illumination Up to 82ft (25m)
• Color / B&W (IR-CUT) Day & Night
• 3D DNR, WDR, ROI, HLC, and BLC Encoding
• Intelligent Analytics
• Built-in MIC
• PoE IEEE082.3af / DC12V±10%, 700mA
• IP67 Ingress Protection
| CAMERA | |
| Image Sensor | 1/2.8" SONY Starvis Back-illuminated CMOS |
| Resolution | 5MP |
| Main Stream | 2592x1944, 2560x1440 @, 1920x1080, 1280x720 / @30fps |
| Sub Stream | 1280x720, 720x480 / @30fps |
| Video Compression | HH.264 / H.265 Compression Available |
| Audio Compression | G.711a / G.711u, AAC |
| TV System | PAL / NTSC |
| Electronic Shutter Speed | Auto: 1/3 - 1/100,000s |
| Min. Illumination | Color: 0.006 Lux @ F1.6 (AGC ON), B/W: 0 Lux with IR |
| S/N Ratio | 60dB |
| Scanning System | Progressive |
| Video Output | Network |
| Reset Button | Optional |
| LENS | |
| Focal Length | 2.8 mm |
| FOV | 106° (H), 56° (V), 127° (D) |
| Lens Type | Fixed Focal Lens, 2.8mm |
| Focus Control | Fixed |
| Aperture | F1.6 |
| Pixels | 5MP |
| NIGHT VISION | |
| IR LED | 42μ x 2PCS |
| IR Distance | 82ft (25m) |
| IR Status | Auto Control |
| IR Power On | Smart, Manual, and Timed modes are available |
| IR Cut Filter | Yes |
| NETWORK | |
| Ethernet | RJ-45 (10/100Base-T) |
| Wireless | N/A |
| Protocol | TCP/IP, IPv4/v6, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP ,PPPoE, NTP, SMTP, UDP, SNMP, Qos, 802.1x |
| ONVIF | Support ONVIF 19.12 (Profile S/T/G) |
| P2P | Yes |
| PoE | Internal, Support IEEE 802.3af |
| Video Delay | 0.3s (Within the LAN) |
| IE Browser | IE8-11, Chrome, Firefox, and Mac Safari |
| AI FUNCTION | |
| Intelligent Analytics | Human & Vehicle Detection, Intrusion Detection, Line Crossing Detection, Loiter Detection, People Gathering Detection, Motion Detection |
| CAMERA FEATURES | |
| Day/Night | Color / B&W (IR-CUT) |
| Image Configuration | Saturation/Brightness/Contrast/Sharpness, Mirror, 3D DNR , White Balance, Anti Flicker, Video Tampering, HLC |
| Corridor Pattern | Yes |
| ROI | Yes |
| BLC | Yes |
| WDR | True WDR |
| Motion Detction | Supported (Enables the detection based on Human Movement only) |
| Privacy Masking | 3 Rectangular Zone |
| Recording Mode | NVR / CMS / Web |
| Language | English, Bulgarian, Polish, Arabic, German, Russian, French, Korean, Portuguese, Japanese, Turkish, Spanish, Hebrew, Chinese, |
| Italian, Netherlands, Czech, Vietnamese | |
| INTERFACE | |
| Audio | Built-in Mic |
| Alarm | N/A |
| RS485 | N/A |
| GENERAL | |
| Housing | Metal, IP67 |
| Anti-cut Bracket | NO |
| Operation Temperature | -4°~140°F (-20°~60°C) / less than ≤ 95% RH |
| Storage Temperature | -4°~140°F (-20°~60°C) / less than ≤ 95% RH |
| Power Source | PoE IEEE082.3af / DC12V±10%, 700mA |
| Dimensions | Ø3.78x3.58in (Ø96.0x91.0mm) |
| Weight | 1.32lbs (600g) |
5MP EVO SERIES IP FIXED TURRET NETWORK CAMERA
-
